HESLY 1.37m high X 1.22m width Military Defense Barrier
Brief Introduction
The HESLY Military Defensive Barriers unit is a PATENT product, which is a multi-cellular barrier system manufactured from welded Hot-dipped galvanised steel wire mesh and joined with vertical, helical-coil joints. The units are lined with a heavy-duty non-woven polypropylene geotextile. When joined and filled, the system can be used to create barriers of exceptional strength and structural integrity.
 |
|
|
| Military Defensive Barrier |
Recoverable Bastion Barrier |
Flood Barrier Wall |
About the newest Recoverable Defensive Barriers
The recoverable Defensive Barriers provides the same high-specification welded mesh and geotextile as standard HMIL units, but the new recoverable feature means that individual cells can be opened by removing just one pin, allowing the fill material to be released from the unit.
Recoverable HMIL units are deployed in exactly the same way as the standard HMIL products. Once the mission is over, efficient recovery for disposal can begin. To recover the units for disposal simply open the cell by removing the pin, this allows the fill material to flow freely from the cell. The units can then be recovered fully intact and flat packed for transportation for recycling or disposal, providing substantial reduction in logistical and environmental impact.
|
|
|
| Recoverable Bastion Barrier |
HESLY Defensive Barrier |
Military Gabion Barrier |
All
HESLY barriers are pre-assembled and delivered palletized with joining pins, to enable the connection of individual units, which can then be filled with available material using minimal manpower and commonly available equipment.
Protection is afforded by the fill material of the structure as a consequence of its mass and physical properties, allied with the proven dynamic properties of Concertainer units.
Whether used as a preventative barrier or to define boundaries, HESLY Gabion Barrier units have been employed to safeguard personnel, vehicles, equipment, facilities and other critical assets in a variety of military, peacekeeping, humanitarian and civilian operations.
Applications include:
- Perimeter security
- Defensive barriers
- Equipment revetments
- Ammunition compounds
- Personnel bunkers
- Observation points
- Guard posts
|
- Ammunition and explosives stores
- Contraband search areas
- Highway checkpoints
- Border crossing checkpoints
- Protecting existing structures
- Traffic management
- Hostile vehicle mitigation
|
General Specifications
| HESLY Military Gabion Barriers |
| MODEL |
CELLS No. |
HEIGHT |
WIDTH |
LENGTH |
| HMIL1R 5442 |
9 (5cells+4cells) |
54’’(1.37M) |
42’’(1.06M) |
32’9’’(10M) |
| HMIL2R 2424 |
2 |
24’’ (0.61M) |
24’’(0.61M) |
4’(1.22M) |
| HMIL3R 3939 |
10 (5cells X 2) |
39’’(1.00M) |
39’’(1.00M) |
32’.9’’(10M) |
| HMIL4R 3960 |
20 (10cells X 2) |
39’’(1.00M) |
60’’(1.52M) |
32’.9’’(10M) |
| HMIL5R 2424 |
5 |
24’’(0.61M) |
24’’(0.61M) |
10’(3.05M) |
| HMIL6R 6624 |
5 |
66’’(1.68M) |
24’’(0.61M) |
10’(3.05M) |
| HMIL7R 8784 |
13 (5cell+4cell+4cell) |
87’’(2.21M) |
84’’(2.13M) |
91’(27.74M) |
| HMIL8R 5448 |
9 (5cells + 4cells) |
54’’(1.37M) |
48’’(1.22M) |
32’.9’’(10M) |
| HMIL9R 3930 |
12 (6cell X 2) |
39’’(1.00M) |
30’’(0.76M) |
30’’(9.14M) |
| HMIL10R 8760 |
20 (5cells X4) |
87’’(2.21M) |
60’’(1.52M) |
100’(32.50M) |
| HMIL11R 4812 |
2 |
48’’(1.22M) |
12’’(0.30M) |
4’(1.22M) |
| HMIL12R 8442 |
30 (5cells X 6) |
84’’(2.13M) |
42’’(1.06M) |
108’(33M) |
| NOTE: We accept OEM/ODM, and can design and make the barriers according to special requirements. |
Reference Photos
|
|
| Illustration of HMil-3 Defensive Barrier |
HMIL-5 Military Gabion Barrier |
|
|
| HESLY Defensive Barrier |
Military Defensive Barriers China Exporter |
|
|
| HESLY Defensive Barrier Factory |
HESLY Defensive Barrier Factory |
|
|
| Flood Barrier |
Flood Barrier |
|
|
| HESLY Defensive Barrier Factory |
HESLY Defensive Barrier |
|
|
| HESCO Defensive Barrier |
HESCO Bastion Barrier |
