| Material: | Galvanised Wire/PVC Coated Wire | Wire Dia.: | BWG17 To BWG27 |
|---|---|---|---|
| Aperture: | 10mm To 100mm | Roll Size: | 1X50m As Standard |
Material :galvanized steel wire and PVC coated steel wire .
Four kinds of Hexagonal Wire Mesh according to differences of manufacturing process:
1,Galvanized Hexagonal Iron Wire Mesh, Straight Twisted
2,Plastic-Coated Hexagonal Wire Mesh, Straight Twisted
3,Galvanized Hexagonal Wire Mesh, Reverse Twisted
4,Galvanized Hexagonal Wire Mesh with Wire Reinforcement, Reverse Twiste
| Hexagonal wire mesh | ||||
| Normal Sizes: Length X Width: 3'x100' (0.914X30.48M) 4'X100'(1.219X30.48M) |
||||
| wire mesh | BWG(Gauge) | Packing dia. (cm) | ||
| Straight Twist (S twist) |
1/2" | 22 | 0.71 | 15 |
| 1/2" | 23 | 0.62 | 15 | |
| 1/2" | 24 | 0.56 | 14 | |
| 1/2" | 25 | 0.51 | 13 | |
| 5/8" | 22 | 0.71 | 15 | |
| 5/8" | 23 | 0.62 | 14 | |
| 5/8" | 24 | 0.56 | 13 | |
| 5/8" | 25 | 0.51 | 12 | |
| 3/4" | 21 | 0.81 | 17 | |
| 3/4" | 22 | 0.71 | 16 | |
| 3/4" | 23 | 0.62 | 15 | |
| 3/4" | 24 | 0.56 | 14 | |
| Double Twist | 1" | 20 | 0.91 | 16 |
| 1" | 21 | 0.81 | 15 | |
| 1" | 22 | 0.71 | 14 | |
| 1" | 23 | 0.62 | 13 | |
| 1" | 24 | 0.56 | 12 | |
| 6/5" | 19 | 1.01 | 17 | |
| 6/5" | 20 | 0.91 | 16 | |
| 6/5" | 21 | 0.81 | 15 | |
| 6/5" | 22 | 0.71 | 15 | |
Reverse Twist (Z twist) |
3/2" | 18 | 1.2 | 20 |
| 3/2" | 19 | 1.01 | 17 | |
| 3/2" | 20 | 0.91 | 16 | |
| 3/2" | 21 | 0.81 | 14.5 | |
| 3/2" | 22 | 0.71 | 14 | |
| 2" | 18 | 1.2 | 18 | |
| 2" | 19 | 1.01 | 17 | |
| 2" | 20 | 0.91 | 15 | |
| 2" | 21 | 0.81 | 14.5 | |
| 2" | 22 | 0.71 | 14 | |
| 3" | 18 | 1.2 | 17 | |
| 3" | 19 | 1.01 | 17 | |
| 3" | 20 | 0.91 | 16 | |
Reference Photos
 |
|
| Stainless Steel Hexagonal Wire Mesh | PVC coated Hexagonal Wire Net |
|
|
| Galvanised Hexagonal Chicken Mesh | Green Color PVC coated Chicken Mesh |
|
|
| Chicken Wire Mesh | Double Twist Wire Mesh |
