Welded Roll Mesh Fencing | 50X50mm square hole | RAL6005 Green PVC coated

Good quality Wind and Dust Control Fence System for sales
Good quality Wind and Dust Control Fence System for sales
Through your words I see a man of wisdom and a man with a great soul. I am grateful for your trust. and I checked the mesh, which is very good !

—— Francis Courrier

We got all the HESCO Barriers. It is good ! The customer is very happy for them ! We had a good deal !

—— Kazuyuki

I'm Online Chat Now

Welded Roll Mesh Fencing | 50X50mm square hole | RAL6005 Green PVC coated

China Welded Roll Mesh Fencing | 50X50mm square hole | RAL6005 Green PVC coated supplier
Welded Roll Mesh Fencing | 50X50mm square hole | RAL6005 Green PVC coated supplier Welded Roll Mesh Fencing | 50X50mm square hole | RAL6005 Green PVC coated supplier Welded Roll Mesh Fencing | 50X50mm square hole | RAL6005 Green PVC coated supplier Welded Roll Mesh Fencing | 50X50mm square hole | RAL6005 Green PVC coated supplier Welded Roll Mesh Fencing | 50X50mm square hole | RAL6005 Green PVC coated supplier

Large Image :  Welded Roll Mesh Fencing | 50X50mm square hole | RAL6005 Green PVC coated

Product Details:

Place of Origin: HESLY Fencing Solutions, China
Brand Name: HESLY
Certification: ISO9001
Model Number: H-HLW-3100

Payment & Shipping Terms:

Minimum Order Quantity: 1X20'GP
Price: US$1.00 to US $2.35/square meters
Packaging Details: Plastic Film
Delivery Time: 7 working days/40' container
Payment Terms: T/T, L/C, D/P at sight, Western Union
Supply Ability: 25000 square meters/day
Contact Now
Detailed Product Description
Material: Low Carton Steel Wire Wire Dia: 1.0mm To 3.0mm
Aperture: 1" To 4" Height: Max. 2.0m
Length: 30m As Standard Coating: PVC Coated

Welded Roll Mesh Fencing | 50X50mm square hole | RAL6005 Green PVC coated

Roll Mesh Fencing is a member of welded mesh fence family(also named welded roll mesh fence) which has special characters different from the ordinarywelded mesh panel, that is waved horizontal wire and straight vertical wire. In addition, it is usually delivered with rolls.

euro mesh fence, roll mesh fencingCompare with other sister welded mesh fence. Euro mesh fence is light duty mesh fence it's much easier to install and transportation one roll euro mesh fence length could up to 50meter length or even longer ,in some way its decrease install work and time of persons.Today euro mesh fence was effected person daily life such as the movie God farther you could see the euro mesh fence,europe like it,especially Italy.

Characteristics of Euro Mesh Fence:

Good corrosion resistance, anti-aging, nice appearance, easy and quick installation.
With refined design, lower price and convenient installation, euro fence is very favorable for the users.
Using high quality steel as raw material, the welded panels body is very plain and strong resistance strength. Especially the horizontal wire is wavy.
It is well suitable for a wide range of applications, for example, for park, road and etc.

Tensile strength of steel wire material

  • Line wire:450--550MPA
  • Cross wire :600-700MPA

welded mesh roll fence China WIRE MESH FENCERoll Mesh fence Specification:

Wire Diameter(mm)Mesh(inch)Mesh(mm)
2.0/3.04''×4''101.6×101.6
2.0/3.04''×3''101.6×50.8
2.0/2.54''×2''101.6×50.8
1.9/2.43''×2''75×50.8
1.9/2.42''×2''50.8×50.8
1.9/2.42''×1''50.8×25.4

Features:
*Strong and rigid construction,
* Consistent mesh size openings throughout the roll
* Uniform opening
* Excellent corrosion resistance, rust resistance and alkeli resistance
* Easy and quick installation
* Euro welded fences have a versatile aesthetic appearance as they can be painted to fit in with any exterior colour scheme.

Welded Mesh Fence Rolls
Reference Photos

Euro Mesh Fencewelded mesh roll fence
Welded Wire Mesh Roll FenceWelded Wire Mesh Roll Fence
holland mesh fencingwelded wire mesh roll fence
Holland Mesh FenceEuro Mesh Fencing
Fence PostFencing Post
Fence PostFence Post
Airport Perimeter Security FencingWelded Wire Mesh Fence
Airport Perimeter Security FencingWelded Wire Mesh Fence

HESLY FENCING SOLUTIONS (HeslyFence®) is China-Based Wire Mesh Fence Designer, Manufacturer & Exporter. Pls don't hesitate to contact us for the fast quoted, Professional and Reliable service.

At HeslyFence, where you can purchase all of your fencing and accessories for your project. With our quality service, you will receive:

>> Quality products at the lowest price
>> Reliable advice from our friendly professional HeslyFence team
>> An efficient order process
>> Delivery to you in time.​
